This is a bid for a dual display universal digital programmable temperature controller that supports many type of thermocouple sensor. It can be powered by 85-265V AC, Comsumption5VA. DIN 1/16.
Display: Dual display for Celsius (C)
Range: 0-1300°C (this range is just for the temperature controller, the attached K type thermocouple is just for 400°C )
Main Output: Relay:
PID cooling/heating control
1 RELAY alarm: Normal open, capacity 250V/3A AC or 30V/3A DC
7 different Dual Output combinations with: high / low / high deviation / low deviation /interval / out of interval / breakage alarm
Input: Thermo Resistor: PT100, Cu50
Thermocouple: J,S,K,E,Wre3 ~ Wre25
Dimension: DIN: 1/8 (48mm x 96mm x 110mm)
Weight: about 300g
Individually programmable PID control parameters.
P, I, d, controlling period, digital filter coefficient, and more
Relay control ready to connect
K type thermocouple: 0-400°C, 2m cable (6 feet).
DIN 1/8 great form-factor to be included/build-in to your product.
Input: TC(K, J, S, E) / RTD (Pt100, CU50) universal input, or 4-20mA signal.
Control output: RELAY
Alarm output: 1 line output, 7 kinds of alarm mode: high/low/high deviation/low deviation/interval/out of interval/breakage alarm.
